Zoned Approach to Power Quality

A Power Quality Solutions focus ensures continued performance and less maintenance on your microprocessor-based equipment.

Power Line Irregularities Happen! Problems such as surges, noise, overvoltage, brown-outs, harmonics and blackouts can, at a minimum cause data disruptions and in some cases can even cause damage to sensitive equipment. Conducting a power quality check-up on your facility and providing a power quality solution for continued performance of microprocessor type equipment using the zoned approach is explained here.



1. Analyze your environment for its effect on electronic equipment.

   • Is severe weather and lightning a common occurrence?

   • Have you experienced nuisance failures, brownouts or other problems?

2. Review the mechanical integrity of all systems.

   • Check for loose wires or misfiring.

   • Check for proper grounding, floating grounds or multiple grounds.

   • Use thermal scanning equipment to locate troubled areas.

3. Identify the problem.

   • Field sample troubled areas with line-monitoring equipment, or define the disruption and potential causes to determine the problem.

4. Evaluate what systems need to be protected in each zone.

   Select power/data quality equipment to address the specific problems.

   Zone 0: If experiencing lightning related spikes, strong RF signals, under-voltages, brownouts or blackouts, provide first level of transient control on all cables (power, voice, data) entering the building.

   Zone 1: Surge voltage and currents from outside the building can appear on all conductive paths. Install hard-wired surge protection devices -- all incoming conductors, connect all system ground conductors to a common ground point, and connect all surge protection devices to the same common ground.

   Zone 2: Residual spikes from service entrance and surges/noise originating within the building can be solved by providing supplemental layers of power/data quality protection in the form of surge protection devices or line conditioners.

   Zone 3 thru end: Additional surges and noise surrounding point-of-use equipment can be solved by protecting distinct pieces of equipment via surge protection devices, line conditioners, isolation transformers, line/load reactors, stand-by power systems, or uninterruptible power supplies.
